UTi740H+

Professional Enhanced Thermal Imager

The UTi740H+ is equipped with a high-sensitivity infrared detector (＜35mK) boasting 400×300 infrared resolution, paired with a 4.3-inch capacitive touchscreen (800×480 pixels) that delivers vivid, detail-rich imaging. Its manual focus ring enables seamless measurement of both near and distant targets. Measurement data can be saved as photos or videos, while Wi-Fi/wired connectivity to APP/PC software facilitates comprehensive data management and analysis—helping you get work done more efficiently.

IR Resolution

400×300

Temperature Range

-20℃ ~ 650℃

Thermal Sensitivity

35mK

Field of View (FOV)

29°×21.5°

Frame Rate

≤30Hz

Display

4.3″ LCD Touch (800×480)

Get a quote

Data Sheet

Download Resources

FEATURES

400×300 High-definition infrared resolution (upscales to 800×600 pixels when super resolution is on)

Lorem ipsum dolor sit amet consectetur. Cursus amet non felis suscipit cursus ultricies nulla non. Nunc morbi proin dictumst purus.

4.3" Capacitive touch display (800×480)

Lorem ipsum dolor sit amet consectetur. Fermentum magna sapien interdum imperdiet platea ligula donec tortor. Augue in orci praesent in dignissim etiam vel. Eu scelerisque at tincidunt dolor venenatis orci malesuada.

Manual focus

Precise high-resolution thermal imaging with fast refresh rates, delivering accurate temperature readings and hot-spot detection for critical diagnostics.

30Hz frame rate

Rugged, reliable, and user-friendly design engineered for demanding electrical, mechanical, and HVAC building diagnostic applications.

Temperature measurement range from -20℃ to 650℃

Advanced on-screen measurement and analysis capabilities with customizable color palettes and seamless report export.

High-accuracy measurement (up to ±1.5℃/±1.5% whicherver is greater)

Equipped with long-lasting rechargeable battery power and durable industrial-grade casing rated for reliable field operations.

Technical Specification

Functions
Technical Data
Display	4.3″ LCD Touch (800×480)
Detector type	UFPA (Vanadium oxide)
IR resolution(Pixels)	400×300
Super resolution(Pixels)	800×600
Spectral range	8~14µm
Pixel size	12µm
Frame rate	≤30Hz
Thermal sensitivity(NETD)	＜35mK
Focus	Manual Focus
Lens focal length	9.5mm
Field of view(FOV)	29°(H) × 21.5°(V)
Spatial resolution(IFOV)	1.26mrad
Temperature measurement range	-20℃ ~ 650℃
Accuracy	0℃~650℃, ±1.5℃ or ±1.5% whichever is greater -10℃~0℃, ±2℃ or ±2% whichever is greater
Color palettes	White Hot, Black Hot, Red Hot, Ironbow, Rainbow HC, Rainbow, Lava
Image modes	Thermal, Visual image, T-Mix fusion, PIP
On screen analyzer	16 Points/16 Lines/16 Rectangles/16 Circles
Isotherm	Auto/Manual/Above/Below/Section
HI/LO temperature alarm	LCD animation & Buzzer
HI/LO temperature tracking	✔
Annotation	Text & Voice
Digital camera resolution	5MP
Digital zoom	1x~6x
Video recording	✔
Voice recording	✔
Wi-Fi / Wi-Fi live streaming	✔
Analysis software	PC+APP
General Characteristics
Battery	5200mAh detachable Li-ion battery pack (UT-M17)
Operating time	Approx. 4 hours (with Wi-Fi off)
USB	Type-C
Storage	Built-in 32GB & 32GB SD card
Image storage format	Radiometric JPEG
Video storage format	MP4 & UIR (with radiometric data)
Protection	IP54 & 2m drop proof
Certificates	CE, FCC, RoHS
Languages	EN, FR, DE, IT, ES, SV, PL, CS
Weight	750g
Dimension	270mm×130mm×110mm
Packing Details
Standard accessories	Type-C USB cable, SD card, Li-ion battery pack×2, Hand Strap, Quick Start Guide, Documents Download Operation Guide
Standard individual packing	Toolbox & Gift box
Standard Qty per carton	1pcs
Standard carton size	400mm×185mm×345mm
Standard carton G.W.	3.6kg
