UTP3300TFL-II
The UTP3000TFL-II Series is an economical linear DC power supply with excellent quality and excellent indicators, with intuitive four-bit LED voltage, current display, short circuit overload, reverse polarity protection and other functions. High stability and high reliability.
Linear
TYPE
1
CHANNELS
150W
TOTAL POWER
30V
OUTPUT VOLTAGE
5A
OUTPUT CURRENT
10mV/1mA
RESOLUTION
Voltage :＜ (0.01% + 3mV) ,Current:≤(0.1% + 5mA)
SETTING ACCURACY
/
CONNECTIVITY
KEY FEATURES
Model
UTP3315TFL-II
MODEL
| Model | Bandwidth | Analog Channels | Real-time Sample Rate | Max. Memory Depth | Waveform Capture Rate | Digital Channels |
|---|---|---|---|---|---|---|
 UTP3315TFL-II |
linear | 1 | 150W | 30V | 5A | 10mV/1mA |
 UTP3313TFL-II |
linear | 1 | 90W | 30V | 3A | 10mV/1mA |
Technical Specification
| Model | UTP3315TFL-II |
| Key Specifications | |
| Type | Linear |
| Channels | 1 |
| Output Voltage | 0–30 V |
| Output Current | 0–5 A |
| Output Power | 150 W |
| Voltage Resolution | 10 mV |
| Current Resolution | 1 mA |
| Technical Details | |
|---|---|
| Ripple And Noise Voltage | ≤2 mVrms |
| Load Regulation CV | ≤0.01%+5 mV |
| Load Regulation CC | ≤0.1%+10 mA |
| Programming Accuracy Voltage | <0.5%+20 mV |
| Programming Accuracy Current | <0.5%+10 mA |
| Features | |
| Protection | OVP/OCP/OTP |
| General Information | |
| Display | 4-digit LED |
| Power | AC 110/220 V ±5%, 50/60 Hz |
| Product Net Weight | 4 kg |
| Product Dimensions (W×H×D) | 105 × 165 × 249 mm |
| Standard Quantity Per Carton | 4 pcs |
| Certification | CE |
| Warranty | 3 Years |
| specifications | Range | Accuracy |
|---|---|---|
| AC Voltage Detection |
0.010Ω-0.199Ω 0.010Ω-0.199Ω 0.010Ω-0.199Ω |
±（1%＋0.02Ω） ±（1%＋0.02Ω） ±（1%＋0.02Ω） |
| Current (AC) |
0.010Ω-0.199Ω 0.010Ω-0.199Ω 0.010Ω-0.199Ω |
±（1%＋0.02Ω） ±（1%＋0.02Ω） ±（1%＋0.02Ω） |
| Features | ||
| Jaw size | 0.010Ω-0.199Ω | |
| Timer | ✔ |
