UT582 Digital RCD (ELCB) Tester

UNI-T’s UT582 is a 1000-count digital RCD (ELCB) tester with phase switch, connections check, AUTO RAMP, disconnect buzzer, over-range display and more. It meets IEC61557 standard.

Get a quote

Data Sheet

Download Resources

Key Features

Features

● Lock measurement

● 1000-count LCD display of all measurement indicators

● Lead sequence check with 3 LED indication lights

● Phase angle selection (0°and 180°), can detect the fastest trigger time

● AUTO RAMP measurement, trip current and time real-time display

● Fuse protection; data hold, over range indication, double insulation

● EN61557-1:2007, EN61557-6:2007

Technical Specification

Features
Specifications		Range		UT582
RCD measurement	Range setting	Rated operating current	Trip time
	X 1/2	10mA/20mA/30mA/100mA/300mA/500mA	2000ms	√
	X 1	10mA/20mA/30mA/100mA/300mA	1000ms	√
	X 1	500mA	300ms	√
	X 5	10mA/20mA/30mA	40ms	√
	AUTO RAMP	10mA/20mA/30mA/100mA/300mA/500mA	300ms	√
	Trip current accuracy			±10%
	Trip time accuracy			±(2%+2)
	Trip time resolution	1ms		√
	Operating voltage (Freq.)	195V~253V (50Hz)		√
Display count				1000
Data hold	0° and 180°			√
Phase switch	Lamps indication			√
Connections check	Simultaneously test the trip time and trip current			√
AUTO RAMP				√
Disconnect buzzer				√
Over-range display	OL			√
Fused				√
Mis-operation buzzer				√
Power off buzzer				√
Full icon display				√
Meets IEC 61557	61557-1:2007; 61557-6:2007			√
General Characteristics
Power	No battery is required
Display	71mm x 34mm
Product color	Red and grey
Product net weight	400g
Product size	160mm x 100mm x 71mm
Standard accessories	Test line, carrying bag, gallus
Standard individual packing	Gift box, English manual
Standard quantity per carton	5pcs
Standard carton measurement	425mm x 280mm x 180mm (0.063 CBM per standard carton)
Standard carton gross weight	4.9kg
